A kilowatt-hour reserve for the home, the van and the workshop
The EcoFlow Delta 3 Plus stores 1024 Wh in a LiFePO4 battery rated for 4000 cycles at 80% capacity. Its four Schuko sockets provide up to 1800 W continuous and 3600 W peak in total, enough to run a computer, lighting and a DIY tool at the same time as long as their power stays within those limits.
Day to day, at home or on the move
At home it takes over from a router, a workstation or a small fridge during an outage. On holiday it goes along with a motorhome, a boat or a cabin. For a professional it equips a mobile workshop, a light food truck, an outdoor event or a survey post. Always check the starting power of each appliance before plugging it in.
Overview of the outputs
- 4 EU Schuko sockets, 230 V, 1800 W continuous in total, 3600 W peak.
- 2 USB-A ports at 36 W each.
- 2 USB-C ports at 140 W each.
- 1 DC output, 12 V/126 W, with a DC5521 connector (12.6 V, 3 A).
Ways to recharge it
From the mains, the charging port takes 1500 W and the station is full again in about 1 hour. On solar, two inputs of 500 W each accept 11 to 60 V and 15 A: you can connect two panel strings as long as you respect those values. Check the voltage and current ratings of your panels before buying cables and connectors.
Build and ergonomics
The case measures 202 × 397.6 × 283.6 mm and weighs 12.5 kg; you can move it one-handed using the handle, but frequent carrying calls for breaks. Bluetooth and Wi-Fi are used to follow charging and adjust settings from a smartphone.
Installation and connection
Choose a flat, ventilated spot sheltered from rain. Route the cables so they do not cross a walkway. To supply a dwelling, make no connection to the electrical panel yourself: that work belongs to a qualified electrician.
Key points
- 1024 Wh for a mass of 12.5 kg.
- 1800 W continuous, 3600 W peak, over four sockets.
- Dual 500 W solar inputs.
- Recharge in about 1 hour.
Technical specifications
- Battery: LiFePO4, 4000 cycles to 80% capacity
- Capacity: 1024 Wh
- USB outputs: 2 × USB-A 36 W, 2 × USB-C 140 W
- DC output: 1 × 12 V/126 W, DC5521 12.6 V 3 A
- 230 V output: 4 Schuko sockets, 1800 W continuous in total, 3600 W peak in total
- Input: mains port 1500 W, solar port 2 × 500 W, 11-60 V, 15 A
- Mains recharge: about 1 hour
- Connectivity: Bluetooth and Wi-Fi
- Dimensions: 202 × 397.6 × 283.6 mm
- Weight: 12.5 kg
Safety
Do not exceed 1800 W continuous, use extension leads of sufficient cross-section and do not cover the ventilation openings. Keep the station away from water and heat sources, and do not open the case.
Care
Clean it with a dry cloth. If it will not be used for a long time, store it somewhere dry, partly charged.
