When the panels are far from the battery
Picture a ground-mounted array at the bottom of a garden, or a roof far from the utility room: cables run long, and the high voltage of module strings helps limit losses. The Victron Energy SmartSolar MPPT 150/35 is designed for this kind of layout. Its input tolerates 150 V, its charge current reaches 35 A and it recognises a 12, 24 or 48 V battery by itself. Built-in Bluetooth gives access to the device from a compatible mobile terminal.
Who it concerns
The home owner enlarging a solar setup for a second residence, the craftsperson installing a standalone system on a work site, the keeper of a small refuge or an isolated guesthouse: all can find a charging stage suited to relatively long strings of modules.
Working out the number of panels
Add up the open-circuit voltages of the modules in a string; the sum, increased to allow for cold, must stay below 150 V. As for power, the datasheet gives 500 W of nominal photovoltaic power at 12 V and 1000 W at 24 V. For 48 V, refer to the manufacturer’s documentation.
Material and size
The housing is made of plastic, measures 130 x 186 x 70 mm and weighs 1250 g. The electronics are protected to IP43 and the connections to IP22, which means it must be installed under cover. Its self-consumption is 10 mA.
Installation steps
- Position the unit vertically, on a sound surface.
- Provide cables of suitable cross-section between the panels and the controller, then between the controller and the battery.
- Connect the battery first, then the panel string, following the manual.
- Open the compatible app to check that the voltage has been recognised.
Connections to a household network and the sizing of protections should be left to a qualified installer.
What counts
- 150 V input for longer panel strings.
- 35 A charge current.
- Three battery voltages recognised automatically.
- Weight of 1250 g.
Specification sheet
- Brand: Victron Energy
- Model: SmartSolar MPPT 150/35
- Charge current: 35 A
- Battery voltage: 12/24/48 V, automatic selection
- Nominal PV power: 500 W (12 V), 1000 W (24 V)
- Input: 150 V
- Output: 12V/500W – 24V/1000W
- Self-consumption: 10 mA
- Protection: IP43 for electronic components, IP22 for connections
- Dimensions: 130 x 186 x 70 mm
- Weight: 1250 g
- Material: plastic
